Model
H8012/H8012SHK
H8015/H8015SHK
Installation Environment
Outdoor/indoor
Input Voltage
AC24V/AC220V
Power
25W（with heater）
Operating Temperature
-5℃~60℃; H:-25℃~60℃
Dimensions(L*W*H)
376*136*103.5mm
453*129*102mm
Viewing Window(W*H)
67*57mm
Max Camera and Lens Size(L*W*H)
174*90*72.5mm
250*90*72.5mm
Weight
1.9 kg
2.6 kg
Cable Entry
Two PG13.5 compression glands on bottom of enclosure,11.9mm Max cable diameter
Latches
Lock Stainless steel;can be secured with padlocks (not supplied)
Camera Mounting
Removable camera sled installed in the strip of two narrow grooves; mounting holes on sled are easy to disassemble.
Optional Accessories
S: Blower(fans) H: Heater K: Sunshield
G: Optical glass
Material
Aluminum Alloy
Recommend Bracket
WS2771:Light-duty wall mounting, max load 15kg
WS2770:Heavy-duty wall mounting, max load 55kg
WS2790:Partially mounted(vertical/horizontal angle adjustable), max load 20kg
Recommended Pan/Tilt
FY-SP10,FY-SP20
